After years of solid and rapid development, MOCHUAN has grown into one of the most professional and influential enterprises in China. high torque servo motor Having devoted a lot to product development and service quality improvement, we have established a high reputation in the markets. We promise to provide every customer throughout the world with prompt and professional service covering the pre-sales, sales, and after-sales services. No matter where you are or what business you are engaged in, we'd love to help you deal with any issue. If you want to know more details about our new product high torque servo motor or our company, feel free to contact us.Wuxi Mochuan Drives Technology Co.,Ltd has guided itself improving quality management systems.
Wuxi Mochuan Drives Technology Co.,Ltd always keeps well informed about the technical development and new product R&D, which guarantees we can develop new products on a regular basis. Manufactured following the strict management system, our 67 Diameter Narrowband Sorting Direct Drive Drum Motor for Logistics Industry Equipment has gained a reliable quality. Before its launch, it has passed the tests based on international rules and is certified by several authorities. MOCHUAN is worth the investment for those customers seeking business opportunities. In the future, Wuxi Mochuan Drives Technology Co.,Ltd will always adhere to the business philosophy of "people-oriented, innovative development", based on excellent quality, driven by technological innovation, committed to high-quality products, high-level technology and high-efficiency operations, and promotes the company The economy develops soundly and rapidly.
| Warranty: | 3months-1year | Place of Origin: | JIANGSU |
| Brand Name: | MOCHUAN | Model Number: | MC-3DM-67N |
| Usage: | For Logistics Industry Equipment | Type: | Brushless Motor |
| Torque: | 5Nm, 5Nm | Construction: | Permanent Magnet |
| Protect Feature: | Drip-proof | Speed(RPM): | 750RPM |
| Continuous Current(A): | 0.6A | Efficiency: | IE4 |
| Motor Type: | Narrowband Sorting Direct Drive Drum Moto | Diameter: | 67mm |
| Feature: | Narrowband Sorting | Drive voltage: | 48VDC |
| MOQ: | NO MOQ, 1pcs is ok | Service: | Supporting OEM diameter, color, shape, parameter...etc |
| Application: | for Logistics Industry Equipment |
Parameter | Unit | Value |
Driver supply voltage Udc | V | 48 |
Number of pole pairs | 7 | |
Rated Speed Nn | rpm | 750 |
Number of winding phases | 3 | |
MaxTorque Tn | Nm | 5 |
No-load Current | Arms | 0.6 |
No-load Speed | rpm | 1185 |
Line Back EMF Coefficient | Vrms/krpm | supporting cusomized±10% |
Torque factor KT | Nm/Arms | 0.44±10% |
Line resistance RI | Ω@20°C | 0.975±10% |
Line inductance LI | mH@1KHz | 2.68±20% |
Insulation class | F | |
Position feedback device | Hall | |
Work schedule | short time |
The application of the QC process is crucial for the quality of the final product, and every organization needs a strong QC department. high torque servo motor QC department is committed to continual quality improvement and focuses on ISO Standards and quality assurance procedures. In these circumstances, the procedure may go more easily, effectively, and precisely. Our excellent certification ratio is a result of their dedication.
Wuxi Mochuan Drives Technology Co.,Ltd always considers communicating through phone calls or video chat the most time-saving yet convenient way, so we welcome your call for asking for the detailed factory address. Or we've displayed our e-mail address on the website, you are free to write an E-mail to us about the factory address.
In China, ordinary working time is 40 hours for employees who work full time. In Wuxi Mochuan Drives Technology Co.,Ltd, most employees work abiding by this kind of rule. During their duty time, each of them devotes their full concentration to their work so as to provide customers with the highest-quality PLC Independent Temperature Controller and an unforgettable experience of partnering with us.
Regarding the attributes and functionality of the high torque servo motor, it is a kind of product that will always be in vogue and offer consumers limitless benefits. It can be a long-lasting friend for people because it is constructed from high-quality raw materials and has a lengthy lifespan.
Yes, if asked, we will supply relevant technical details regarding MOCHUAN. Basic facts about the products, such as their primary materials, specs, forms, and primary functions, are readily available on our official website.
Regarding the attributes and functionality of the high torque servo motor, it is a kind of product that will always be in vogue and offer consumers limitless benefits. It can be a long-lasting friend for people because it is constructed from high-quality raw materials and has a lengthy lifespan.
Wuxi Mochuan Drives Technology Co.,Ltd is one manufacturer and engineering company in three series PLC programmable logic controller, three different types of HMI touch screen panel and switching power supply.
