With strong R&D strength and production capabilities, MOCHUAN now has become a professional manufacturer and reliable supplier in the industry. All our products including Human Machine Interface Touch Screen are manufactured based on the strict quality management system and international standards. Human Machine Interface Touch Screen We promise that we provide every customer with high-quality products including Human Machine Interface Touch Screen and comprehensive services. If you want to know more details, we are glad to tell you.The product is popular in domestic and foreign market and has remarkable market potential.
| Model | 7Inch M007 Multi-Touch Capacitive HMI Panel
|
|---|
| Touch Screen Type | Glass+Glass Projective Multi-Touch |
| CPU | 600MHZ ARM Cortex-A8 + 128M Flash+128MB DDR3 |
Display | LCD Visual Angle | 70'/70'/75'/75' |
| Screen Size | 7inch 16:9 tft lcd screen |
| Resolution | 1024x600 |
| Colors | 24 |
| Brightness | 350cd/m2 |
| BackLight | LED |
| BackLife | 50000 Hours |
Storage | Flash/ARM | 128MB Flash+ 128MB DDR3 |
| SD Card | Support |
| RTC | Built-in |
Ports | Serial Port | COM1:RS232/RS485/RS422; COM2/COM4:RS485; COM3:RS232 |
| Ethernet | 1x 10M/100M Self-Adaption |
| Download Project | USB Disk/ USB Device/ Ethernet |
Power | Power Supply | DC24V, Working Range: DC9V~DC28V |
| Rated Power | ＜6W |
| Power Protection | Protected From Thunder Strike And Surging |
| Power Down | ＜5mS |
| Operating Humidity | 10~90% RH( No Condensation) |
| Vibration Endurance | 10~25HZ (X,Y,Z 2G/30Min) |
Dimension | Shell Material | Aluminium Alloy + Engineering Plastic |
| Dimension(mm) | 185.1mm x 131.1mm x 30mm |
| Panel Cutout(mm) | 178mm x 135mm |
| Weight(g) | 650g |
Environment | Protection | Front IP65( with NEMA panel), Back IP20 |
| Temperature Operate | -10°C~60°C |
| Temperature Storage | -20°C~70°C |
The others | Certificate | CE |
| Communication Protocol | Standard Modbus( RTU, TCP/IP) |
| Programming Software | Free Mochuanstudio
|
1. NO MOQ, 1pcs is OK.
2. 7days refund in case of bad quality; 36months warranty.
3. Offering the translation project file service, if wanna switch the other brand HMI to be Mochuan's.
4. It can prepare the models for customer urgent order, to shorten the delivery time, just one wrods, if you work with us.
5. Offering demo, description file, remote help etc, any you like the way, to solve the technical problem through one-to-one online service.
M007 7Inch Clearness, High Brightness, Transparent
Mochuan multi touch capacitive HMI panel is very clearness, high brightness, high resolution is up to 1920x1080 and transparent, like the apple mobile, will bring the user different experience. For now the only bright spots in the indstury market, will be easy to win in your competitor. The display resolution is the number of pixels displayed on the screen.For example, the resolution of 1920x1080 means that the number of pixels in the horizontal direction is 1920 and the number of pixels in the vertical direction is 1080.
7'' M007 HMI With A Strong CPU
ARM CortexA8 processor, high speed and easy flow, supporting animation formats. The ARM Cortex-A8 processor is the 1st application processor based on the ARMv7 architecture and is the highest performance and most power efficient processor ever developed by ARM. with rates in the 600MHz to over 1GHz range, the Cortex-A8 processor is capable of meeting the requirements of mobile devices that need to operate at power-optimized rates below 300mW; and Meet the requirements of consumer applications that require the performance optimization of 2000 Dhrystone MIPS.
Mochuan M007 7Inch With A Good Working Life
HMI capacitive touchscreens for industrial displays will last longer because the components in the capacitive touchscreen do not require any movement. In resistive touch screens, the upper ITO film needs to be thin enough to be flexible enough to bend down to contact the underlying ITO film.
Multi-Touch Capacitive HMI
Supporting multi-touch and gesture, specific page effect can be realized. To upgrade the latest advances in human computer interaction technilogy, easily completing complex tasks between point and click. Capacitive screen to achieve multi-touch, relying on the increase in mutual capacitance of the electrode, simply put, is the screen is divided into blocks, in each area set a group of mutual capacitance module are working independently, so the capacitive screen can independently detect the touch situation in each area, after processing, simply to achieve multi-touch.
Capacitive Multi-Touch HMI
7inch M007
9.7inch M010
9.7inch MC5097X
17inch MC5170
22inch MC5220
Plastic Economic Resistive HMI
4.3inch MC-H043S
7inch MC-H070/ MC-H070W
7inch MC-H070S/MC-H070SW
10.1inch MC-H100/MC-H100W/MC-H100D
10.1inch MC-H100E/MC-H100EW/MC-H100DE
15.6inch MC-H156E
Metal Shell Wide-Temperature Resistive HMI
4.3inch MC4043E
7inch MC4070M
7inch MC4070E
9.7inch MC4097X
12.1inch MC4121X
15inch MC4150X
Material of Shell: Front cover is aluminum, the surface with hard oxide treatment +back is made of galvanized sheet, is with dry spray treatment;
Feature:
New design, very popular in market; IPS full view tft lcd; Supporting multi-touch and gesture; It deserve to try in sample, then you will know it all;
Material of Shell: ABS
Feature:
7inch support 1024x600 resolution, and the maximum viewing angle is 170°, which brings a better sensory experience to customers; The display size, parameters, resolution, COM port and the other configuration multiple options; Very high advantage competitive and high stability; Energy-saving and environmental protection;
With very strong CPU 1GHz CortexTM-A7 and 4GB Flash+128MB DDR3.
Material of Shell: Aluminum front cover +the back over is made of galvanized sheet, and the surface is with dry spray treatment.
Feature:
Working temperature is from-20°C to +70°C, and stroge temperature is from -30° to 80°C; Metal enclosure, fine heat dispersion and strong anti-interference;
1. Is the HMI software free or to charge?
Mochuan HMI Software Mochuanstudio is free for the user. You can take from"download-software" if you need.
2. Is there any suggestion on selecting model of HMI?
Yes, it is good to take two minutes to read this article"how to select a suitable and high advantage competitive model hmi for the project", trusting it will be some helpful on selecting hmi model and type.
3. Is there any service, if swtich another brand hmi to be Mochuan's?
Yes, Providing translation engineering file services, if you wanna switch to be Mochuan HMI.
4. Is there any certificate of HMI?
Yes, Mochuan HMI support CE and RoHs.
