Mochuan 9.7 Inch Industrial HMI Touch Screen TFT HMI Panel MC5097X

Name: Mochuan 9.7 Inch Industrial HMI Touch Screen TFT HMI Panel MC5097X
Uploaded: 2022-08-19T18:07:28+08:00
Duration: 1 min 11 s
Description: To promote the product advantages, we have successfully introduced modern technologies to the manufacturing process of readable daylight 7" capacitive industrial hmi touch screen tft lcd.The more multi-functional the product is, the more broadly it will be used. It is widely used in the field(s) of Touch Screen Monitors.

To promote the product advantages, we have successfully introduced modern technologies to the manufacturing process of readable daylight 7" capacitive industrial hmi touch screen tft lcd.The more multi-functional the product is, the more broadly it will be used. It is widely used in the field(s) of Touch Screen Monitors.

SEND INQUIRY NOW

Type:: LCD

shipping:: within 10days after confirmation

Model Number:: MC5097X

Screen Size:: 9.7"

Resolution:: 1024x768

Ethernet:: 1x10M/100M self-adaption

samples:: NO MOQ, 1pcs is ok

Screen Type:: Capacitive

Supplier Type:: Original manufacturer

Brightness:: 350cd/m2

Voltage(V):: 24VDC

CPU:: 600MHz ARM Cortex-A8

Color:: black

Bit Color:: 24bits

COM Port:: COM1,COM2,COM3,COM4,RS485,RS232,RS422

SEND INQUIRY NOW

Product Details

WHY MOCHUAN HMI

1. Rich performance, very stable quality, and the most important is very high advantage competitive, very beautiful in price; 2. To create a technical supporting group ONLY for you through one-to-one service online, if you deal with us, not need through public service telephone to waste the time and engery, to realize fastly solve; 3. Directly factory sale, to help customers quickly match the model through our over a decade of field experience and industry solutions, achieving a truly cost-controlled solution or win market solution;

MARKET BRAND HMI

1. Very stable quality, rich performance but low usage probability with expensive. It is like a luxury car that has too many features and functions but it actually used very little, for example, Siemens brand, Mitsubishi, etc; 2. Only through public service telephone service, have to restate the problem for every calling, becuase people who pick up are different; 3. There are many different agent levels, it is difficult to get the first level price for buyers.

MC5097X Parameter

/ 7'' Multi Touch Capacitive HMI Panel

You May Interested In.

MOCHUAN DRIVES All 7'' HMI Model Parameters Comparison Diagram, Click Here To Learn More.

Model	9.7Inch MC5097 Multi-Touch Capacitive HMI Panel
Touch Screen Type	Glass+Glass Projective Multi-Touch
CPU	600MHZ ARM Cortex-A8 + 128M Flash+128MB DDR3
Display	LCD Visual Angle	85'/85'/85'/85'
	Screen Size	9.7inch 4:3 tft lcd screen
	Resolution	1024x768
	Colors	24-bits
	Brightness	350cd/m2
	BackLight	LED
	BackLife	50000 Hours
Storage	Flash/ARM	128MB Flash+ 128MB DDR3
	SD Card	Support
	RTC	Built-in
Ports	Serial Port	COM1/COM2:RS232/RS485/RS422; COM3/COM4:RS232
	Ethernet	1x 10M/100M Self-Adaption
	Download Project	USB Disk/ USB Device/ Ethernet
Power	Power Supply	DC24V, Working Range: DC9V~DC28V
	Rated Power	＜10W
	Power Protection	Protected From Thunder Strike And Surging
	Power Down	＜5mS
	Operating Humidity	10~90% RH( No Condensation)
	Vibration Endurance	10~25HZ (X,Y,Z 2G/30Min)
Dimension	Shell Material	Aluminium Alloy + Engineering Plastic
	Dimension(mm)	247mm x 197mm x 31.5mm
	Panel Cutout(mm)	232mm x 182mm
	Weight(g)	1250g
Environment	Protection	Front IP65( with NEMA panel), Back IP20
	Temperature Operate	-10°C~60°C
	Temperature Storage	-20°C~70°C
The others	Certificate	CE
	Communication Protocol	Standard Modbus( RTU, TCP/IP)
	Programming Software	Free Mochuanstudio

Deserve To Know

/ Service from Mochuan

1. NO MOQ, 1pcs is OK.
2. 7days refund in case of bad quality; 36months warranty.
3. Offering the translation project file service, if wanna switch the other brand HMI to be Mochuan's.
4. It can prepare the models for customer urgent order, to shorten the delivery time, just one wrods, if you work with us.
5. Offering demo, description file, remote help etc, any you like the way, to solve the technical problem through one-to-one online service.

MC5097X 9.7 inch HMI Panel Clearness, High Brightness, Transparent

Mochuan multi touch capacitive HMI panel is very clearness, high brightness, high resolution is up to 1920x1080 and transparent, like the apple mobile, will bring the user different experience. For now the only bright spots in the indstury market, will be easy to win in your competitor. The display resolution is the number of pixels displayed on the screen.For example, the resolution of 1920x1080 means that the number of pixels in the horizontal direction is 1920 and the number of pixels in the vertical direction is 1080. When the HMI touch screen panel size is the same, the higher resolution, the better of the display effect, fine and delicate. With more brilliant colors, wider viewing angles, higher brightness and clearer resolution. The HMI touch screen monitor resolution is high, which improves the viewing experience and visual impact in advance. At the same time, it can realize 4K display, industrial-grade panel, stable and durable, support continuous booting, high brightness, no reflection phenomenon, suitable for long events, close viewing, high contrast ratio, Rich colors, with splicing function, support for cross-screen overlay, roaming overlay display, mature technology, low after-sales rate.

More Features

/ 9.7'' MC5097X HMI

MOCHUAN HMI 9.7Inch MC5097X With Strong CPU

ARM CortexA8 processor, high speed and easy flow, supporting animation formats.RM has announced its latest Cortex-A8 processor, which will bring significant changes to consumer and low-power mobile products, enabling end users to enjoy a higher level of entertainment and innovation. Announced at the second annual ARM Developer Conference in California, the ARM Cortex-A8 processor is capable of up to 2000DMIPS, making it the best choice for increasingly demanding consumer products running multi-channel video, audio and gaming applications. At 65nm, the ARM Cortex-A8 processor consumes less than 300 milliwatts of power, enabling it to deliver industry-leading performance and power efficiency.

Multi-Touch Capacitive HMI Panel

Supporting multi-touch and gesture, specific page effect can be realized. To upgrade the latest advances in human computer interaction technilogy, easily completing complex tasks between point and click.

MC5097X Ports Description

/ MC5097X HMI

FAQ

/ MOCHUAN HMI

1. Is the MC5097X 9.7Inch HMI software free or to charge?

Mochuan HMI software Mochuanstudio is free for the user, you can take from" download-software" if you need.

2. What is guarantee of HMI MC5097X do you offer?

7days refund in case of bad quality; And 36months warranty.

3. Is there any suggestion on selecting model of HMI?

Yes, it is good to take two minutes to read this article" how to select a suitable and high advantage competitive model HMI for the project", trusting it will be some helpful on selecting hmi model and type.

4. Is there any service, if change another brand HMI tobe Mochuan's?

Yes, providing translation engineering file services, if you wanna switch to be Mochuan HMI.

5. Is there any certificate of HMI?

Yes, Mochuan HMI support CE and RoHs.
