|Touch Screen Type||4wire resistive touch screen |
|Color of Shell||White|
|CPU||1G ARM Cortex-A8|
|LCD Visual Angle||85'/85'/85'/85'|
|Screen Size||15.6'' 16:9 tft lcd screen|
|Memory||128M Flash+128M DDR3|
|SD Card||TF card|
|Serial Port||COM1:RS232/RS485/RS422; COM2:RS422/RS485; COM3:RS232|
|Download Project||USB Disk/ USB Device|
|Power Supply||DC24V, Working Range: DC18V~DC28V|
|Power Protection||Protected From Thunder Strike And Surging|
|Operating Humidity||10~90% RH( No Condensation)|
|Vibration Endurance||10~25HZ (X,Y,Z 2G/30Min)|
|Shell Material||Aluminum Alloy|
|Dimension(mm)||394mm x 256mm x 36mm|
|Panel Cutout(mm)||380mm x 245mm or VESA Install|
|Protection||Front IP65( with NEMA panel), Back IP20|
|Communication Protocol||Standard Modbus( RTU,)|
|Programming Software||Free Mochuanstudio 2.8.11490.0|
1. NO MOQ, 1pcs is OK.
2. 7days refund in case of bad quality; 36months warranty.
3. Offering the translation project file service, if wanna switch the other brand HMI to be Mochuan's.
4. It can prepare the models for customer urgent order, to shorten the delivery time, just one wrods, if you work with us.
5. Offering demo, description file, remote help etc, any you like the way, to solve the technical problem through one-to-one online service.
MC-H156E 15.6Inch Clearness, High Brightness, High advantage competitive
Mochuan 15.6inch MC-H156E, the LED backlight uses light-emitting diodes as the backlight light source, and does not require lamps, so the thickness of the light guide plate is greatly reduced, and the thickness of the entire group of backlight plates can be reduced by about half. With 1920x1080 reolution, and 1G ARM Cortex-A8 strong cpu.
MOCHUAN 15.6'' HMI Adapot Industrial Isolated Power Module
Industrial isolated power module, the surface is with spray coating treatment and applicable to various harsh environment. Isolation: Little interference between primary and secondary sides, input and output can have large voltage difference, ACDC or DCAC must be isolated. Disadvantages: Complex structure, many devices, high cost. But greatly improve the stability of the product and the ability to adapt to complex environments.
15.6'' MOCHUAN HMI Support Animation Formats
ARM CortexA8 processor, high speed and easy flow, supporting animation formats. The GIF format supports lossless compression. Lossless compression is an effective way to compress images without losing details, and since the GIF format uses lossless compression, it is more suitable for lines, icons and drawings.
MOCHUAN 15.6'' HMI With A Strong CPU
ARM CortexA8 processor, high speed and easy flow, supporting animation formats.For the first time, the ARM Cortex-A8 processor brings desktop-level performance to a low cost, high volume product. The ARM Artisan library supporting Intelligent Energy Manger (IEM) technology and advanced leakage control techniques enable the Cortex-A8 processor to achieve exceptional speed and power efficiency. the Cortex-A8 processor is supported by a wide range of ARM technologies that enable fast system design. These include:RealView DEVELOPOER software development tools, RealView ARCHITECT ESL tools and models, CoreSight debug and trace technology, and software library support for the OpenMAX multimedia processing standard.
Capacitive Multi-Touch HMI
Plastic Economic Resistive HMI
7inch MC-H070/ MC-H070W
Metal Shell Wide-Temperature Resistive HMI
Material of Shell: Front cover is aluminum, the surface with hard oxide treatment +back is made of galvanized sheet, is with dry spray treatment;
New design, very popular in market; IPS full view tft lcd; Supporting multi-touch and gesture; It deserve to try in sample, then you will know it all;
Material of Shell: ABS
7inch support 1024x600 resolution, and the maximum viewing angle is 170°, which brings a better sensory experience to customers; The display size, parameters, resolution, COM port and the other configuration multiple options; Very high advantage competitive and high stability; Energy-saving and environmental protection;
Material of Shell: Aluminum front cover +the back over is made of galvanized sheet, and the surface is with dry spray treatment.
Working temperature is from-20°C to +70°C, and stroge temperature is from -30° to 80°C; Metal enclosure, fine heat dispersion and strong anti-interference;
1. Is there any suggestion on selecting model of HMI?
Yes, it is good to take two minutes to read this article" how to select a suitable and high advantage competitive model HMI for the project"trusting it will be some helpful on selecting hmi model and type.
2. Is there any service, if switch another brand hmi to be Mochuan's?
Yes, providing translation engineering file service, if you wanna switch to be Mochuan HMI.
3. Is there any certificate of HMI?
Yes, Mochuan HMI support CE and RoHs.
