MOCHUAN industrial text HMI Display Panel metal 4 wire resistive 7inch compared with similar products on the market, it has incomparable outstanding advantages in terms of performance, quality, appearance, etc., and enjoys a good reputation in the market.MOCHUAN summarizes the defects of past products, and continuously improves them. The specifications of MOCHUAN industrial text panel display hmi MC4070M metal 4 wire resistive 7inch 7inch can be customized according to your needs.
Our engineers and technicians have deep insight into the new technological developments. So far, we have been adopting the upgraded technologies maturel It is popular in the application field(s) of Industrial Computer & Accessories.
| Model | 7Inch MC4070E Metal Resistive HMI Display Panel | |
|---|---|---|
| Touch Screen Type | 4wire resistive touch screen | |
| CPU | 600MHZ ARM9 Cortex-A8 | |
Display | LCD Visual Angle | 50'/70'/70'/70' |
| Screen Size | 7inch 16:9 tft lcd screen | |
| Resolution | 800x480 | |
| Colors | 24bits | |
| Brightness | 360cd/m2 | |
| BackLight | LED | |
| BackLife | 50000 Hours | |
Storage | Flash/ARM | 128MB Flash+128ARM DDR3 |
| SD Card | Support | |
| RTC | Built-in | |
Ports | Serial Port | COM1/COM2:RS232/RS485/RS422; COM3/COM4:RS232 |
| Ethernet | 1x10M/100M Self-Adaptin | |
| Download Project | USB Disk/ USB Device | |
Power | Power Supply | DC24V, Working Range: DC9V~DC28V |
| Rated Power | ＜10W | |
| Power Protection | Protected From Thunder Strike And Surging | |
| Power Down | ＜5mS | |
| Operating Humidity | 10~90% RH( No Condensation) | |
| Vibration Endurance | 10~25HZ (X,Y,Z 2G/30Min) | |
Dimension | Shell Material | Aluminum Alloy + Galvanized Sheet Powder Spraying |
| Dimension(mm) | 200mm x 146mm x 40mm | |
| Panel Cutout(mm) | 192mm x 138mm | |
| Weight(g) | 1080g | |
Environment | Protection | Front IP65( with NEMA panel), Back IP20 |
| Temperature Operate | -20°C~70°C | |
| Temperature Storage | -30°C~80°C | |
The others | Certificate | CE |
| Communication Protocol | Standard Modbus( RTU, TCP/IP) | |
| Programming Software | Free Mochuanstudio | |
1. NO MOQ, 1pcs is OK.
2. 7days refund in case of bad quality; 36months warranty.
3. Offering the translation project file service, if wanna switch the other brand HMI to be Mochuan's.
4. It can prepare the models for customer urgent order, to shorten the delivery time, just one wrods, if you work with us.
5. Offering demo, description file, remote help etc, any you like the way, to solve the technical problem through one-to-one online service.
Mochuan 4.3Inc MC4043E is metal enclosure, fine heat dispersion and strong anti-interference. Metal enclosure, fine heat dispersion and strong anti-interference.In the high frequency electromagnetic field, the use of thin layer of metal as a shell or lining material can achieve good shielding effect. The 7 Inch HMI Display Panel represents a pivotal innovation in user interface technology, designed to facilitate intuitive interaction between users and complex systems. Featuring a vibrant touch screen with high-resolution capabilities, this panel allows for the seamless visualization of data and real-time controls across various applications, including industrial automation, home automation, and medical devices. Its compact form factor not only optimizes space efficiency but also enhances portability without compromising on functionality. The versatile connectivity options available—such as USB, Ethernet, and serial interfaces—enable easy integration into existing setups while ensuring swift communication with controlling devices or computers. Moreover, the 7 Inch HMI Display Panel often comes equipped with customizable software solutions that empower users to tailor the graphical user interface (GUI) according to specific operational needs or branding requirements. With robust build quality suited for demanding environments coupled with energy-efficient technologies, this display panel exemplifies how modern engineering can elevate user experience by bridging advanced technology with practical usability.
MOCHUAN 7'' MC4070E HMI Panel Support Animation Formats
ARM CortexA8 processor, high speed and easy flow, supporting animation formats. The GIF format supports graphic progression. Progressive means that the image is gradually displayed on the screen. Progressive images will appear on the screen faster than non-progressive images, allowing visitors to get a quicker overview of the image
7inch M007
9.7inch M010
9.7inch MC5097X
17inch MC5170
22inch MC5220
4.3inch MC-H043S
7inch MC-H070/ MC-H070W
7inch MC-H070S/MC-H070SW
10.1inch MC-H100/MC-H100W/MC-H100D
10.1inch MC-H100E/MC-H100EW/MC-H100DE
15.6inch MC-H156E
4.3inch MC4043E
7inch MC4070M
7inch MC4070E
9.7inch MC4097X
12.1inch MC4121X
15inch MC4150X
Material of Shell: Front cover is aluminum, the surface with hard oxide treatment +back is made of galvanized sheet, is with dry spray treatment;
Feature:
New design, very popular in market; IPS full view tft lcd; Supporting multi-touch and gesture; It deserve to try in sample, then you will know it all;
Feature:
7inch support 1024x600 resolution, and the maximum viewing angle is 170°, which brings a better sensory experience to customers; The display size, parameters, resolution, COM port and the other configuration multiple options; Very high advantage competitive and high stability; Energy-saving and environmental protection;
Feature:
Working temperature is from-20°C to +70°C, and stroge temperature is from -30° to 80°C; Metal enclosure, fine heat dispersion and strong anti-interference;
1. What technical support do you offer?
Offering demo, pdf description file, video and technical supporting one-to-one online, through creating only online group for you, to fast solve the technical, if you work with us.
2. Is there any suggestion on selecting model of HMI?
Yes, it is good to take two minutes to read this article"how to select a suitable and high advantage competitive model hmi for the project", trusting it will be some helpful on selecting hmi model and type.
3. Is there any service, if swtich another brand hmi to be Mochuan's?
Yes, Providing translation engineering file services, if you wanna switch to be Mochuan HMI.
4. Is there any certificate of HMI?
Yes, Mochuan HMI support CE and RoHs.
