|Touch Screen Type||4wire resistive touch screen |
|Color of Shell||White|
|CPU||4core 1.2GHz ARM Cortex-A7|
|LCD Visual Angle||85'/85'/85'/85'|
|Screen Size||7'' 16:9 tft lcd screen|
|Memory||4GB EMMC + 256MB DDR3|
|Serial Port||COM1:RS232/RS485/RS422; COM2:RS485; COM3:RS232|
|Download Project||USB Disk/ USB Device/Ethernet|
|Power Supply||DC24V, Working Range: DC9V~DC28V|
|Power Protection||Protected From Thunder Strike And Surging|
|Operating Humidity||10~90% RH( No Condensation)|
|Vibration Endurance||10~25HZ (X,Y,Z 2G/30Min)|
|Shell Material||Engineering Plastic|
|Dimension(mm)||204mm x 145mm x33.8mm|
|Panel Cutout(mm)||192mm x 138mm|
|Protection||Front IP65( with NEMA panel), Back IP20|
|Communication Protocol||Standard Modbus( RTU,)|
|Programming Software||Free Mochuanstudio 2.8.11490.0|
1. NO MOQ, 1pcs is OK.
2. 7days refund in case of bad quality; 36months warranty.
3. Offering the translation project file service, if wanna switch the other brand HMI to be Mochuan's.
4. It can prepare the models for customer urgent order, to shorten the delivery time, just one wrods, if you work with us.
5. Offering demo, description file, remote help etc, any you like the way, to solve the technical problem through one-to-one online service.
MC-H070SW 7Inch Clearness, High Brightness, High advantage competitive
Mochuan 7inch MC-H070SW, the LED backlight uses light-emitting diodes as the backlight light source, and does not require lamps, so the thickness of the light guide plate is greatly reduced, and the thickness of the entire group of backlight plates can be reduced by about half. The power consumption is reduced, and the LED itself has high luminous efficiency. In general, it can save about 40% of the power consumption of the display screen. Under the same power condition, it directly improves the battery life.
MOCHUAN 7'' HMI Adapot ABS+PC enclosure
The biggest advantage of resistive touch screen is that its screen and control system are cheaper, better response sensitivity, and whether it is a four-wire resistive touch screen or five-wire resistive touch screen, they are in a completely isolated working environment to the outside world, not afraid of dust and moisture, can adapt to a variety of harsh environments
7inch MC-H070SW HMI MOCHUAN With Spray Coating Treatment PCB
Industrial isolated power module, the surface is with spray coating treatment and applicable to various harsh environment. In the application process of the product power isolation chip for power isolation design is very important, if the environmental requirements of power isolation is not taken into account will lead to system instability
Supporting Animation Formats
ARM CortexA8 processor, high speed and easy flow, supporting animation formats.The Cortex-A8 processor has also received future support from major EDA and operating system providers. The Cortex-A8 processor is the first application processor based on the next-generation ARMv7 architecture to use Thumb-2 technology that delivers higher performance, power efficiency and code density. The Cortex-A8 solution also includes Jazelle-RCT Java acceleration technology, which provides optimization for real-time (JIT) and dynamically adapted compilation (DAC) while reducing memory footprint by up to three times. In addition, the new processor is equipped with TrustZone technology for secure transactions and digital rights management, as well as IEM capabilities for low-power management.
Capacitive Multi-Touch HMI
Plastic Economic Resistive HMI
7inch MC-H070/ MC-H070W
Metal Shell Wide-Temperature Resistive HMI
Material of Shell: Front cover is aluminum, the surface with hard oxide treatment +back is made of galvanized sheet, is with dry spray treatment;
New design, very popular in market; IPS full view tft lcd; Supporting multi-touch and gesture; It deserve to try in sample, then you will know it all;
Material of Shell: ABS
7inch support 1024x600 resolution, and the maximum viewing angle is 170°, which brings a better sensory experience to customers; The display size, parameters, resolution, COM port and the other configuration multiple options; Very high advantage competitive and high stability; Energy-saving and environmental protection;
Material of Shell: Aluminum front cover +the back over is made of galvanized sheet, and the surface is with dry spray treatment.
Working temperature is from-20°C to +70°C, and stroge temperature is from -30° to 80°C; Metal enclosure, fine heat dispersion and strong anti-interference;
1. What technical support do you offer?
Offering demo, pdf description file, video and technical supporting one-to-one online, through creating only online group for you, to fast solve the technical, if you work with us.
2. Is there any suggestion on selecting model of HMI?
Yes, it is good to take two minutes to read this article"how to select a suitable and high advantage competitive model hmi for the project", trusting it will be some helpful on selecting hmi model and type.
3. Is there any service, if swtich another brand hmi to be Mochuan's?
Yes, Providing translation engineering file services, if you wanna switch to be Mochuan HMI.
4. Is there any certificate of HMI?
Yes, Mochuan HMI support CE and RoHs.
