MOCHUAN 10 HMI Touch Panel 1024x600 ethernet tcp rs485 tcp dc24v ip65 9.7inch MC-H100E for industrial compared with similar products on the market, it has incomparable outstanding advantages in terms of performance, quality, appearance, etc., and enjoys a good reputation in the market.MOCHUAN summarizes the defects of past products, and continuously improves them. The specifications of MOCHUAN 10 hmi touch screen 1024x600 ethernet tcp rs485 tcp dc24v ip65 9.7inch MC-H100E for industrial can be customized according to your needs.
Our engineers and employees are well trained to utilize state-of-the-art technologies skillfully. So Mochuan 7inch MC-H070S low price hmi easy view for plc can be specially designed to meet the widely varying needs. At present, it is typically used in the field(s) of Touch Screen Monitors.
| Model | MC-H100E | |
|---|---|---|
| Touch Screen Type | 4wire resistive touch screen | |
| Color of Shell | Black | |
| CPU | 4core 1.2GHz ARM Cortex-A7 | |
Display | LCD Visual Angle | 85'/85'/85'/85' |
| Screen Size | 10.1'' 16:9 tft lcd screen | |
| Resolution | 1024x 600 | |
| Colors | 24 bits | |
| Brightness | 400cd/m² | |
| BackLight | LED | |
| BackLife | 50000 Hours | |
Storage | Memory | 4GB EMMC + 256MB DDR3 |
| SD Card | Support | |
| RTC | Built-in | |
Ports | Serial Port | COM1:RS232/RS485/RS422; COM2:RS485; COM3:RS232 |
| Ethernet | 1x10M/100M Self-adation | |
| Download Project | USB Disk/ USB Device/Ethernet | |
Power | Power Supply | DC24V, Working Range: DC9V~DC28V |
| Rated Power | ＜10W | |
| Power Protection | Protected From Thunder Strike And Surging | |
| Power Down | ＜5mS | |
| Operating Humidity | 10~90% RH( No Condensation) | |
| Vibration Endurance | 10~25HZ (X,Y,Z 2G/30Min) | |
Dimension | Shell Material | Engineering Plastic |
| Dimension(mm) | 237mm x 213mm x36mm | |
| Panel Cutout(mm) | 260mm x 202mm | |
| Weight(g) | 900g | |
Environment | Protection | Front IP65( with NEMA panel), Back IP20 |
| Temperature Operate | 0°C~50°C | |
| Temperature Storage | -20°C~60°C | |
The others | Certificate | CE |
| Communication Protocol | Standard Modbus( RTU,) | |
| Programming Software | Free Mochuanstudio 2.8.11490.0 | |
1. NO MOQ, 1pcs is OK.
2. 7days refund in case of bad quality; 36months warranty.
3. Offering the translation project file service, if wanna switch the other brand HMI to be Mochuan's.
4. It can prepare the models for customer urgent order, to shorten the delivery time, just one wrods, if you work with us.
5. Offering demo, description file, remote help etc, any you like the way, to solve the technical problem through one-to-one online service.
Mochuan 10.1 inch HMI MC-H100E with ethernet and 1024x600 resolution, 16:9 tft lcd, the LED backlight uses light-emitting diodes as the backlight light source, and does not require lamps, so the thickness of the light guide plate is greatly reduced, and the thickness of the entire group of backlight plates can be reduced by about half. The power consumption is reduced, and the LED itself has high luminous efficiency. In general, it can save about 40% of the power consumption of the display screen. Under the same power condition, it directly improves the battery life.
HMI Touch Panel offers a myriad of benefits that revolutionize the way we interact with machines. Utilizing state-of-the-art touch screen technology and intuitive user interfaces, the HMI Touch Panel enables seamless control over complex industrial processes with just a simple swipe or tap. Its responsive nature empowers operators to swiftly navigate through vast amounts of data and effortlessly adjust parameters in real-time. With its stunning visual displays and customizable layouts, this cutting-edge tool enhances productivity by providing clear and concise information at a glance.
Additionally, the HMI Touch Panel streamlines operations by eliminating the need for physical buttons or switches, reducing clutter and increasing workspace efficiency. This advanced device also facilitates remote monitoring capabilities, allowing users to access critical data from anywhere in the world via secure network connections. The HMI Touch Panel truly embodies innovation at its finest – empowering businesses across industries to optimize performance while ensuring user-friendly experiences like never before imagined.
How do select druing in MC-H100E, MC-H100EW, MC-H100ED and MC-H100CWE HMI
Mochuan 10.1'' hmi with ethernet have three models, what is different during of them.
Three of them are with the same technical parameters and datasheet. MC-H100E is black color shell, MC-H100EW with a white color shell and with 260mm x 202mm panel cutout.
MC-H100ED is black color shell with ethernet, just different on its panel cutout is 261mm x 180mm.
The model of MC-H100CEW is belong to white color shell with ethernet, but with a very strong CPU 1GHz, CortexTM-A7, 4GB Flash+128DDR3 with 260mm x 202mm panel cutout.
So when select 1.01'' hmi during of them, kindly check the color, panel cutout and CPU, which one is more sutiable of your project, to choose the most suitable model HMI for your project.
7inch M007
9.7inch M010
9.7inch MC5097X
17inch MC5170
22inch MC5220
4.3inch MC-H043S
7inch MC-H070/ MC-H070W
7inch MC-H070S/MC-H070SW
10.1inch MC-H100/MC-H100W/MC-H100D
10.1inch MC-H100E/MC-H100EW/MC-H100DE
15.6inch MC-H156E
4.3inch MC4043E
7inch MC4070M
7inch MC4070E
9.7inch MC4097X
12.1inch MC4121X
15inch MC4150X
Material of Shell: Front cover is aluminum, the surface with hard oxide treatment +back is made of galvanized sheet, is with dry spray treatment;
Feature:
New design, very popular in market; IPS full view tft lcd; Supporting multi-touch and gesture; It deserve to try in sample, then you will know it all;
Feature:
7inch support 1024x600 resolution, and the maximum viewing angle is 170°, which brings a better sensory experience to customers; The display size, parameters, resolution, COM port and the other configuration multiple options; Very high advantage competitive and high stability; Energy-saving and environmental protection;
Feature:
Working temperature is from-20°C to +70°C, and stroge temperature is from -30° to 80°C; Metal enclosure, fine heat dispersion and strong anti-interference;
1. What technical service do you support?
Offering demo, pdf description file, video and technical supporting group online by one-to-one, if work with us.
2. Is there any suggestion on selecting model of HMI?
Yes, it is good to take two minutes to read this article" how to select a suitable and high advantage competitive model HMI for the project"trusting it will be some helpful on selecting hmi model and type.
3. Is there any service, if switch another brand hmi to be Mochuan's?
Yes, providing translation engineering file service, if you wanna switch to be Mochuan HMI.
4. Is there any certificate of HMI?
Yes, Mochuan HMI support CE and RoHs.
