|Model||7Inch M007 Multi-Touch Capacitive HMI Panel|
|Touch Screen Type||Glass+Glass Projective Multi-Touch|
|CPU||600MHZ ARM Cortex-A8 + 128M Flash+128MB DDR3|
|LCD Visual Angle||70'/70'/75'/75'|
|Screen Size||7inch 16:9 tft lcd screen|
|Flash/ARM||128MB Flash+ 128MB DDR3|
|Serial Port||COM1:RS232/RS485/RS422; COM2/COM4:RS485; COM3:RS232|
|Ethernet||1x 10M/100M Self-Adaption|
|Download Project||USB Disk/ USB Device/ Ethernet|
|Power Supply||DC24V, Working Range: DC9V~DC28V|
|Power Protection||Protected From Thunder Strike And Surging|
|Operating Humidity||10~90% RH( No Condensation)|
|Vibration Endurance||10~25HZ (X,Y,Z 2G/30Min)|
|Shell Material||Aluminium Alloy + Engineering Plastic|
|Dimension(mm)||185.1mm x 131.1mm x 30mm|
|Panel Cutout(mm)||178mm x 135mm|
|Protection||Front IP65( with NEMA panel), Back IP20|
|Communication Protocol||Standard Modbus( RTU, TCP/IP)|
|Programming Software||Free Mochuanstudio|
1. NO MOQ, 1pcs is OK.
2. 7days refund in case of bad quality; 36months warranty.
3. Offering the translation project file service, if wanna switch the other brand HMI to be Mochuan's.
4. It can prepare the models for customer urgent order, to shorten the delivery time, just one wrods, if you work with us.
5. Offering demo, description file, remote help etc, any you like the way, to solve the technical problem through one-to-one online service.
M007 7Inch Clearness, High Brightness, Transparent
Mochuan multi touch capacitive HMI panel is very clearness, high brightness, high resolution is up to 1920x1080 and transparent, like the apple mobile, will bring the user different experience. For now the only bright spots in the indstury market, will be easy to win in your competitor. The display resolution is the number of pixels displayed on the screen.For example, the resolution of 1920x1080 means that the number of pixels in the horizontal direction is 1920 and the number of pixels in the vertical direction is 1080. When the HMI touch screen panel size is the same, the higher resolution, the better of the display effect, fine and delicate. With more brilliant colors, wider viewing angles, higher brightness and clearer resolution. The HMI touch screen monitor resolution is high, which improves the viewing experience and visual impact in advance. At the same time, it can realize 4K display, industrial-grade panel, stable and durable, support continuous booting, high brightness, no reflection phenomenon, suitable for long events, close viewing, high contrast ratio, Rich colors, with splicing function, support for cross-screen overlay, roaming overlay display, mature technology, low after-sales rate.
MOCHUAN 7'' M007 Support Multi Touch
The multi-point touch screen can perfectly realize various multi-point exit applications such as picture zooming and rotation, and has all the functions and advantages of the traditional single-point infrared touch screen. The multi-touch capacitive screen mainly has two parts of work, one is to collect multi-point signals at the same time, and the other is to judge the meaning of each signal, which is the so-called gesture recognition. Compared to touch technology, which can only accept single-point input, multi-touch technology allows users to touch the display in multiple places at the same time, so as to be able to zoom and rotate web pages or pictures. The multi-touch screen is responsive, and the response speed can achieve the fastest response speed of 5ms.
Strong Environmental Adaptability
HMI adopts industrial-grade high quality components, high protection level level design and comprehensive three-proof coating, no matter it is a wet underground mine, high temperature gobi or factory environment with corrosive gas, oil mist or dust, it can easily cope with its ease.
Capacitive Multi-Touch HMI
Plastic Economic Resistive HMI
7inch MC-H070/ MC-H070W
Metal Shell Wide-Temperature Resistive HMI
Material of Shell: Front cover is aluminum, the surface with hard oxide treatment +back is made of galvanized sheet, is with dry spray treatment;
New design, very popular in market; IPS full view tft lcd; Supporting multi-touch and gesture; It deserve to try in sample, then you will know it all;
Material of Shell: ABS
7inch support 1024x600 resolution, and the maximum viewing angle is 170°, which brings a better sensory experience to customers; The display size, parameters, resolution, COM port and the other configuration multiple options; Very high advantage competitive and high stability; Energy-saving and environmental protection;
With very strong CPU 1GHz CortexTM-A7 and 4GB Flash+128MB DDR3.
Material of Shell: Aluminum front cover +the back over is made of galvanized sheet, and the surface is with dry spray treatment.
Working temperature is from-20°C to +70°C, and stroge temperature is from -30° to 80°C; Metal enclosure, fine heat dispersion and strong anti-interference;
1. Is there any suggestion on selecting model of HMI?
Yes, it is good to take two minutes to read this article"how to select a suitable and high advantage competitive model hmi for the project", trusting it will be some helpful on selecting hmi model and type.
2. Is there any service, if swtich another brand hmi to be Mochuan's?
Yes, Providing translation engineering file services, if you wanna switch to be Mochuan HMI.
3. Is there any certificate of HMI?
Yes, Mochuan HMI support CE and RoHs.
