WHY MOCHUAN HMI
1. Rich performance, very stable quality, and the most important is very high advantage competitive, very beautiful in price; 2. To create a technical supporting group ONLY for you through one-to-one service online, if you deal with us, not need through public service hotline telephone to waste the time and engery, to realize fastly solve; 3. Directly factory sale, to help customers quickly match the model through our over a decade of field experience and industry solutions, achieving a truly cost-controlled solution or win market solution;
PK
MARKET BRAND HMI
1. Very stable quality, rich performance but low usage probability with expensive. It is like a luxury car that has too many features and functions but it actually used very little, for example, Siemens brand, Mitsubishi, etc; 2. Only through publick service hotline, have to restate the problem for every calling, becuase people who pick up are different; 3. There are many different agent levels, it is difficult to get the first level price for buyers.
M007 Parameter

/ 7'' Multi Touch Capacitive HMI




Model7Inch M007 Multi-Touch Capacitive HMI Panel
Touch Screen TypeGlass+Glass Projective Multi-Touch
CPU600MHZ ARM Cortex-A8 + 128M Flash+128MB DDR3






Display

LCD Visual Angle70'/70'/75'/75'
Screen Size7inch  16:9 tft lcd screen
Resolution1024x600
Colors24
Brightness350cd/m2
BackLightLED
BackLife50000 Hours


Storage

Flash/ARM128MB Flash+ 128MB DDR3
SD CardSupport
RTCBuilt-in



Ports

Serial PortCOM1:RS232/RS485/RS422; COM2/COM4:RS485; COM3:RS232
Ethernet1x 10M/100M Self-Adaption
Download ProjectUSB Disk/ USB Device/ Ethernet





Power

Power SupplyDC24V, Working Range: DC9V~DC28V
Rated Power<6W
Power ProtectionProtected From Thunder Strike And Surging
Power Down<5mS
Operating Humidity10~90% RH( No Condensation)
Vibration Endurance10~25HZ (X,Y,Z 2G/30Min)



Dimension

Shell MaterialAluminium Alloy + Engineering Plastic
Dimension(mm)185.1mm x 131.1mm x 30mm
Panel Cutout(mm)178mm x 135mm
Weight(g)650g


Environment

ProtectionFront IP65( with NEMA panel), Back IP20
Temperature Operate-10°C~60°C
Temperature Storage-20°C~70°C


The others

CertificateCE
Communication ProtocolStandard Modbus( RTU, TCP/IP)
Programming SoftwareFree Mochuanstudio
Deserve To Know

/ Service from Mochuan



  1. 1. NO MOQ, 1pcs is OK.

  2. 2. 7days refund in case of bad quality; 36months warranty.

  3. 3. Offering the translation project file service, if wanna switch the other brand HMI to be Mochuan's.

  4. 4. It can prepare the models for customer urgent order, to shorten the delivery time, just one wrods, if you work with us.

  5. 5. Offering demo, description file, remote help etc, any you like the way, to solve the technical problem through one-to-one online service.


M007 7Inch Clearness, High Brightness, Transparent
Mochuan multi touch capacitive HMI panel is very clearness, high brightness, high resolution is up to 1920x1080 and transparent, like the apple mobile, will bring the user different experience. For now the only bright spots in the indstury market, will be easy to win in your competitor. The display resolution is the number of pixels displayed on the screen.For example, the resolution of 1920x1080 means that the number of pixels in the horizontal direction is 1920 and the number of pixels in the vertical direction is 1080. When the HMI touch screen panel size is the same, the higher resolution, the better of the display effect, fine and delicate. With more brilliant colors, wider viewing angles, higher brightness and clearer resolution. The HMI touch screen monitor resolution is high, which improves the viewing experience and visual impact in advance. At the same time, it can realize 4K display, industrial-grade panel, stable and durable, support continuous booting, high brightness, no reflection phenomenon, suitable for long events, close viewing, high contrast ratio, Rich colors, with splicing function, support for cross-screen overlay, roaming overlay display, mature technology, low after-sales rate.
More Features
/ 7'' M007 Ethernet Multi Touch HMI




MOCHUAN M007 With Strong CPU


ARM CortexA8 processor, high speed and easy flow, supporting animation formats.Cortex-A uses NEON technology, which is specifically designed for multimedia and signal processing. At the same time, Jazelle RCT technology is also used to support pre-compilation and real-time compilation of JAVA programs. For the Cortex-A8, ARM provides a new library (Artisan Advantage - CE). The new library can effectively increase the speed of exception handling and reduce power consumption. The new library also provides advanced memory leak control mechanisms.





Multi-Touch Capacitive HMI
Supporting multi-touch and gesture, specific page effect can be realized. To upgrade the latest advances in human computer interaction technilogy, easily completing complex tasks between point and click. In order to realize the multi-touch function, the multi-touch screen adopts a completely different structure from the single-point touch screen. From the outside of the screen, the single-touch screen has only a few signal lines, while the multi-touch screen has many leads; from the inside, the conductive layer of the single-touch screen is just a flat panel, while the multi-touch screen is divided on the flat panel. There are many relatively independent touch units, each touch unit is connected to an external circuit through an independent lead, and all touch units are arranged in a matrix on the board. In this way, when the user's finger touches a certain part on the screen, a signal will be output from the corresponding detection line. When the finger moves to another location, a signal is output from another detection line.




M007 Ports Description
/ 7Inch M007 HMI





si
Related Products
/ Mochuan HMI




Capacitive Multi-Touch HMI

7inch M007

9.7inch M010

9.7inch MC5097X

17inch MC5170

22inch MC5220


Plastic Economic Resistive HMI

4.3inch MC-H043S

7inch MC-H070/ MC-H070W

7inch MC-H070S/MC-H070SW

10.1inch MC-H100/MC-H100W/MC-H100D

10.1inch MC-H100E/MC-H100EW/MC-H100DE

15.6inch MC-H156E

Metal Shell Wide-Temperature Resistive HMI

4.3inch MC4043E

7inch MC4070M

7inch MC4070E

9.7inch MC4097X

12.1inch MC4121X

15inch MC4150X




Material of Shell: Front cover is aluminum, the surface with hard oxide treatment +back is made of galvanized sheet, is with dry spray treatment;


Feature:

New design, very popular in market; IPS full view tft lcd; Supporting multi-touch and gesture; It deserve to try in sample, then you will know it all;


Material of Shell: ABS


Feature:

7inch support 1024x600 resolution, and the maximum viewing angle is 170°, which brings a better sensory experience to customers; The display size, parameters, resolution, COM port and the other configuration multiple options; Very high advantage competitive and high stability; Energy-saving and environmental protection;

With very strong CPU 1GHz CortexTM-A7 and 4GB Flash+128MB DDR3.






Material of Shell:  Aluminum front cover +the back over is made of galvanized sheet, and the surface is with dry spray treatment.


Feature:

Working temperature is from-20°C to +70°C, and stroge temperature is from -30° to 80°C; Metal enclosure, fine heat dispersion and strong anti-interference;

FAQ
/ MOCHUAN HMI



1. Is there any suggestion on selecting model of HMI?

Yes, it is good to take two minutes to read this article"how to select a suitable and high advantage competitive model hmi for the project", trusting it will be some helpful on selecting hmi model and type.


2. Is there any service, if swtich another brand hmi to be Mochuan's?

Yes, Providing translation engineering file services, if you wanna switch to be Mochuan HMI.


3. Is there any certificate of HMI?

Yes, Mochuan HMI support CE and RoHs.
