WHY MOCHUAN HMI
1. Rich performance, very stable quality, and the most important is very high advantage competitive, very beautiful in price; 2. To create a technical supporting group ONLY for you through one-to-one service online, if you deal with us, not need through public hotline telephone to waste the time and engery, to realize fastly solve; 3. Directly factory sale, to help customers quickly match the model through our over a decade of field experience and industry solutions, achieving a truly cost-controlled solution or win market solution;
PK
MARKET BRAND HMI
1. Very stable quality, rich performance but low usage probability with expensive. It is like a luxury car that has too many features and functions but it actually used very little, for example, Siemens brand, Mitsubishi, etc; 2. Only through public hotline telephone service, have to restate the problem for every calling, becuase people who pick up are different; 3. There are many different agent levels, it is difficult to get the first level price for buyers.
9.7'' M010 Parameter

/ 9.7'' Multi Touch Capacitive HMI




Model9.7Inch M010 Multi-Touch Capacitive Industrial HMI Touch Screen
Touch Screen TypeGlass+Glass Projective Multi-Touch
CPU4core 1.2GHz ARM Cortex-A7






Display

LCD Visual Angle85'/85'/85'/85'
Screen Size9.7inch  4:3 tft lcd screen
Resolution1024x768
Colors24bits
Brightness350cd/m2
BackLightLED
BackLife50000 Hours


Storage

Flash/ARM4G eMMC +256M DDR3
SD CardSupport
RTCBuilt-in



Ports

Serial PortCOM1:RS232/RS485/RS422; COM2/COM4:RS485; COM3:RS232
Ethernet1x 10M/100M Self-Adaption
Download ProjectUSB Disk/ USB Device/ Ethernet





Power

Power SupplyDC24V, Working Range: DC9V~DC28V
Rated Power<8W
Power ProtectionProtected From Thunder Strike And Surging
Power Down<5mS
Operating Humidity10~90% RH( No Condensation)
Vibration Endurance10~25HZ (X,Y,Z 2G/30Min)



Dimension

Shell MaterialAluminium Alloy + Engineering Plastic
Dimension(mm)247mm x 197mm x 31.5mm
Panel Cutout(mm)230mm x 180mm
Weight(g)1115g


Environment

ProtectionFront IP65( with NEMA panel), Back IP20
Temperature Operate-10°C~60°C
Temperature Storage-20°C~70°C


The others

CertificateCE
Communication ProtocolStandard Modbus( RTU, TCP/IP)
Programming SoftwareFree Mochuanstudio 2.8.11490.0
Deserve To Know

/ Service from Mochuan



  1. 1. NO MOQ, 1pcs is OK.

  2. 2. 7days refund in case of bad quality; 36months warranty.

  3. 3. Offering the translation project file service, if wanna switch the other brand HMI to be Mochuan's.

  4. 4. It can prepare the models for customer urgent order, to shorten the delivery time, just one wrods, if you work with us.

  5. 5. Offering demo, description file, remote help etc, any you like the way, to solve the technical problem through one-to-one online service.


M010 9.7 Inch Industrial HMI Touch Screen Clearness, High Brightness, Transparent
Mochuan multi touch capacitive HMI panel is very clearness, high brightness, high resolution is up to 1920x1080 and transparent. Multi-touch definition from the application, multi-touch screen's biggest feature is that you can two or three hands, multiple fingers, or even multiple people, while operating the contents of the screen, more convenient and humane, multi-touch technology is also called multi-touch technology, such as IPHONOE's use of two fingers on the screen to zoom in and out of the picture.
More Features
/ 9.7'' M010 HMI Panel




Mochuan 9.7Inch HMI M010 Strong CPU


ARM CortexA8 processor, high speed and easy flow, supporting animation formats.Cortex-A uses NEON technology, which is specifically designed for multimedia and signal processing. At the same time, Jazelle RCT technology is also used to support pre-compilation and real-time compilation of JAVA programs. For the Cortex-A8, ARM provides a new library (Artisan Advantage - CE). The new library can effectively increase the speed of exception handling and reduce power consumption. The new library also provides advanced memory leak control mechanisms.


Mochuan HMI Support Animation Formats


ARM CortexA8 processor, high speed and easy flow, supporting animation formats. supporting animation formats.The GIF animation format, like PNG, is a format commonly used on the web, and can be used to store multiple color images. Advantages: small size, ideal for use on the web, and the ability to create animations. Disadvantages. It can only contain up to 256 colors.


Mochuan Industrial HMI Touch Screen M010 Support Multi-Touch
M010 Multi-touch definition from the application, multi-touch screen's biggest feature is that you can two or three hands, multiple fingers, or even multiple people, while operating the contents of the screen, more convenient and humane, multi-touch technology is also called multi-touch technology, such as IPHONOE's use of two fingers on the screen to zoom in and out of the picture
M010 Ports Description
/ 9.7''M010 HMI Panel





si
FAQ
/ MOCHUAN HMI




1. What technical support do you offer?

Offering demo, pdf description file, video and technical supporting one-to-one online, through creating only online group for you, to fast solve the technical, if you work with us.


2. Is there any suggestion on selecting model of HMI?

Yes, it is good to take two minutes to read this article" how to select a suitable and high advantage competitive model hmi for the project". trusting it will be some helpful on selecting hmi model and type.


3. Is there any service, if switch another brand hmi to be Mochuan's?

Yes, providing translation engineering file services, if you wanna switch to be Mochuan HMI.


4. Is there any certificate of HMI?

Yes, Mochuan HMI support CE and RoHs.
